Add physical safe shutdown switch to Stratux FLARM

Alexander Dross
June 14, 2021
Physical shutdown switch for Stratux FLARM on Raspberry Pi GPIO pins
Physical shutdown switch for Stratux FLARM on Raspberry Pi GPIO pins

I have seen the idea to support a physical switch to trigger the shutdown command on your Stratux FLARM, powered by a Raspberry PI 3 or 4, rather than just cutting the power which will most likely result in issues with the micro SD card.

  • Why a Safe Shutdown Switch?
  • What You Need
  • Hardware Setup
  • GPIO Pin Selection
  • Wiring Diagram
  • Software Configuration
  • Step 1: Enable GPIO Shutdown
  • Step 2: Edit the boot configuration
  • Step 3: Reboot to apply changes
  • Testing the Switch
  • Alternative: Shutdown Script
  • Button Placement Ideas
  • LED Indicator (Optional)
  • Safety Considerations
  • Conclusion
  • Related Resources

I have seen the idea to support a physical switch to trigger the shutdown command on your Stratux FLARM, powered by a Raspberry PI 3 or 4. This is much safer than just cutting the power, which can corrupt the SD card.

Why a Safe Shutdown Switch?

When you simply cut power to a Raspberry Pi:

  • The file system may be corrupted
  • The SD card can be damaged over time
  • You may lose configuration changes
  • Log files may be incomplete

A proper shutdown sequence:

  • Closes all open files
  • Unmounts the file system cleanly
  • Prepares the SD card for power off
  • Preserves your data and settings

What You Need

  • Momentary push button switch
  • Two jumper wires
  • Basic soldering skills (optional, can use breadboard)
  • Access to Raspberry Pi GPIO pins

Hardware Setup

GPIO Pin Selection

We'll use:

  • GPIO 21 (Pin 40): Signal input from the button
  • Ground (Pin 39): Ground connection

Wiring Diagram

Button Terminal 1 -----> GPIO 21 (Pin 40)
Button Terminal 2 -----> Ground (Pin 39)

The button connects GPIO 21 to ground when pressed.

Software Configuration

Step 1: Enable GPIO Shutdown

SSH into your Stratux:

ssh pi@192.168.10.1
bash

Step 2: Edit the boot configuration

sudo nano /boot/config.txt
bash

Add this line at the end:

dtoverlay=gpio-shutdown,gpio_pin=21

Step 3: Reboot to apply changes

sudo reboot
bash

Testing the Switch

1. Wait for Stratux to fully boot

2. Press and hold the shutdown button for about 3 seconds

3. The Raspberry Pi should initiate shutdown

4. Wait for the green LED to stop blinking

5. The system is now safe to power off

Alternative: Shutdown Script

For more control, you can create a custom shutdown script:

#!/usr/bin/env python3
import RPi.GPIO as GPIO
import os
import time

GPIO.setmode(GPIO.BCM)
GPIO.setup(21, GPIO.IN, pull_up_down=GPIO.PUD_UP)

def shutdown_callback(channel):
    time.sleep(0.5)  # Debounce
    if GPIO.input(21) == GPIO.LOW:
        os.system("sudo shutdown -h now")

GPIO.add_event_detect(21, GPIO.FALLING, callback=shutdown_callback, bouncetime=300)

while True:
    time.sleep(1)
python

Save as /home/pi/shutdown_button.py and add to startup.

Button Placement Ideas

  • External case button: Drill a hole in your Stratux case
  • Quick-disconnect: Use a connector for easy removal
  • Panel mount: Install on your aircraft panel if permanent

LED Indicator (Optional)

Add a status LED to show when it's safe to remove power:

GPIO 20 (Pin 38) -----> LED (+) -----> 330Ω Resistor -----> Ground

Modify the shutdown script to turn on the LED when shutdown is initiated.

Safety Considerations

  • Use a momentary switch to prevent accidental shutdowns
  • Consider adding a confirmation delay (hold for 3 seconds)
  • Label the button clearly
  • Test thoroughly before flying

Conclusion

Adding a safe shutdown switch to your Stratux is a simple modification that can save you from SD card corruption and data loss. The hardware cost is minimal, and the peace of mind is worth it.

Happy building and safe flying!
